WorldFlow3D

WorldFlow3D: Flowing Through 3D Distributions for Unbounded World Generation (ECCV 2026).

Amogh Joshi, Julian Ost, Felix Heide

Diffusers-native inference for WorldFlow3D — hierarchical, map/layout-conditioned 3D scene generation via chunked flow matching. A self-contained inference package: pretrained cascades load straight from the Hugging Face Hub with nothing but PyTorch and diffusers.

Code is Apache-2.0. Released models are trained on datasets with their own terms. In particular the Waymo models are non-commercial (Waymo Open Dataset License) — see Licensing, WAYMO_NOTICE.md, and THIRD_PARTY_LICENSES.md.

Roadmap

✅ Inference code (worldflow3d package)

✅ Front3D (indoor) checkpoints

✅ Waymo (WOD) checkpoints

✅ PyPI package (pip install worldflow3d)

⬜ Map processing (raw scenes → conditioning maps) — mid July 2026

⬜ Training code — mid July 2026

⬜ Additional indoor layouts — end of July 2026

Install

pip install worldflow3d            # core (torch, diffusers, trimesh, scikit-image, ...)
pip install "worldflow3d[layout]"  # + h5py, for loading Front3D/ScanNet++ .h5 layouts

PyTorch is expected to be installed for your CUDA/CPU platform. Requires torch>=2.2 and diffusers>=0.29; tested on torch 2.2 / diffusers 0.29.2, torch 2.5 / diffusers 0.38, and torch 2.12 / diffusers 0.38 (CUDA 13, aarch64) (NumPy 1.x and 2.x both work).

Running on aarch64 / DGX Spark (GB10)

On an aarch64 host with a Blackwell GB10 (CUDA 13), the standard PyPI/conda torch wheels don't target the platform — install torch from the CUDA-13 (cu130) index first, then the package:

pip install torch torchvision --index-url https://download.pytorch.org/whl/cu130
pip install "worldflow3d[examples]"   # + tyro, for the CLI example scripts
pip install accelerate                # optional: quiets the model-load warning

Only the NVIDIA driver is needed — no separate CUDA toolkit — since the cu130 wheel ships its own CUDA runtime. For the fast path on GB10, add --simultaneous --compile to the CLI (Python: simultaneous=True, compile=True on from_hub / from_converted).

Reference timings on GB10 (Waymo coarse→refine, cfg_scale=1.5, 30+30 steps, smaller_map=True, fraction=0.12, segment 1172406780360799916, 1 coarse + 49 refine chunks): simultaneous=True + compile=True ~21 min, simultaneous=False + compile=True ~50 min, simultaneous=False + compile=False ~2h20m

GB10 is memory-bandwidth-bound here (~244 GB/s unified, vs ~768 GB/s on an A6000 and ~3.35 TB/s on an H100), so treat these as platform reference numbers, not a general benchmark — discrete GPUs are substantially faster.

Quickstart

Each cascade stage is a subfolder of a Hub repo (<dataset>-coarse, plus <dataset>-refine / -color). The Waymo and Front3D cascades live in separate repos (Waymo is non-commercial — see Licensing). Load with from_hub:

import torch
from worldflow3d import WorldFlow3DPipeline
from worldflow3d.pipeline.datatypes import LayoutContext
from worldflow3d.conditioning.waymo import load_waymo_map_json
from worldflow3d.recon import save_mesh

# Waymo coarse -> refine cascade, straight from the Hub (non-commercial).
pipe = WorldFlow3DPipeline.from_hub(
    "pci-lab/worldflow3d-waymo", stage="waymo-coarse", refinement_stages=["waymo-refine"],
    device="cuda",
)

# A shipped sample map -- self-contained: no coord transform or data root needed.
map_json = load_waymo_map_json("1172406780360799916", map_dir="examples/sample_maps")
ctx = LayoutContext("waymo", "1172406780360799916", map_json)

result = pipe(layout_context=ctx, cfg_scale=1.5, sampling_steps=30,
              refine=True, refine_sampling_steps=30, use_uniform_chunking=True,
              simultaneous=True, smaller_map=True, fraction=0.12)

save_mesh(result.voxels.cpu(), result.voxel_size, "scene.ply")

CLI (--repo/--stage for the Hub, or --model-dir for local dirs):

python -m worldflow3d.scripts.generate_streets \
    --repo pci-lab/worldflow3d-waymo --stage waymo-coarse --refine-stage waymo-refine \
    --segment 1172406780360799916 --map-dir examples/sample_maps \
    --cfg-scale 1.5 --coarse-steps 30 --refine-steps 30 \
    --smaller-map --fraction 0.12 --use-uniform-chunking --simultaneous \
    --output outputs/segment-1172406780360799916.ply

The sample maps used above ship in the repository under examples/sample_maps/ (they are not bundled in the PyPI wheel). Point --map-dir / map_dir= at any directory of map JSONs.

For a colored scene, use the color refinement stage. The color model is tag-conditioned (location / time_of_day / weather) — pass tags for a coherent result; without them the color channels are unconditioned and the mesh shows color/surface artifacts. save_mesh also writes a colored <name>_color.ply.

python -m worldflow3d.scripts.generate_streets \
    --repo pci-lab/worldflow3d-waymo --stage waymo-coarse --refine-stage waymo-color \
    --segment 1172406780360799916 --map-dir examples/sample_maps \
    --cfg-scale 1.5 --coarse-steps 30 --refine-steps 30 \
    --smaller-map --fraction 0.12 --use-uniform-chunking --simultaneous \
    --coarse-tag location=location_sf \
    --refine-tag time_of_day=Dawn/Dusk --refine-tag weather=sunny \
    --output outputs/segment-1172406780360799916_color.ply

From Python, pass tags= / refine_tags= to the pipeline, e.g. refinement_stages=["waymo-color"] with tags={"location": "location_sf"}, refine_tags={"time_of_day": "Dawn/Dusk", "weather": "sunny"}. Valid values: location ∈ {location_sf, location_phx, location_other}; time_of_day ∈ {Dawn/Dusk, Day, Night}; weather ∈ {sunny, rain}.

Indoor (Front3D), layout-conditioned coarse → color refinement:

python -m worldflow3d.scripts.generate_indoor \
    --repo pci-lab/worldflow3d --stage front3d-coarse --refine-stage front3d-color \
    --scene-id <uuid> --data-root front3d_scenes --refine --output outputs/scene.ply

Models / repo layout

Each stage is a self-contained diffusers layout in its own subfolder. The model code is supplied by this package, so the subfolders carry only weights + config (no duplicated .py). The Waymo and Front3D cascades are in separate repos because they carry different licenses:

pci-lab/worldflow3d-waymo/   (NON-COMMERCIAL — Waymo Open Dataset License)
├── waymo-coarse/     model_index.json  unet/{config.json, *.safetensors}  scheduler/
├── waymo-refine/     "    (source-flow refinement, geometry only)
└── waymo-color/      "    (source-flow refinement, geometry + color, unet in=4)

pci-lab/worldflow3d/         (Front3D — 3D-FRONT terms)
├── front3d-coarse/   "
└── front3d-color/    "    (source-flow + color, unet in=4)

waymo-refine and waymo-color are alternative refinement stages for the same coarse output — pick one. waymo-color also predicts per-voxel color, so save_mesh writes an extra colored <name>_color.ply sidecar. Each unet/ folder is a distinct trained model (different weights and configs), not a copy.

Loading

Source	Call	Needs
Hub (cascade)	WorldFlow3DPipeline.from_hub(repo, stage, refinement_stages=[...])	pip install worldflow3d
Local dirs	WorldFlow3DPipeline.from_converted(coarse_dir, [refine_dir, ...])	converted dirs on disk
Bare diffusers	DiffusionPipeline.from_pretrained(repo, trust_remote_code=True)	a model at the repo root only

Why no subfolder= one-liner? diffusers.DiffusionPipeline.from_pretrained does not apply subfolder at the pipeline level — it reads model_index.json only from the repo root (true even on the latest diffusers). So the subfolder/cascade layout is loaded via from_hub (this package). The bare-diffusers trust_remote_code one-liner works only for a model published at a repo root.

Design (diffusers-native)

Component	Class	Notes
Model	WorldFlow3DUNet(ModelMixin, ConfigMixin)	wraps the 3D UNet; save_pretrained/from_pretrained (safetensors)
Scheduler	WorldFlow3DFlowScheduler(SchedulerMixin, ConfigMixin)	velocity-prediction Euler flow matching
Pipeline	WorldFlow3DPipeline(DiffusionPipeline)	custom __call__: chunking, CFG, source-flow + standard reconstruction, coarse→refine cascade, sequential + simultaneous

Default models are direct-diffusion (voxel-space; no VAE). A VAE-decode path is wired but optional. Classifier-free guidance, the model-time scaling, and the inpainting blend live in the pipeline; the scheduler does only the per-step Euler update.

Licensing

WorldFlow3D ships under multiple licenses depending on the artifact:

Artifact	License
Code (worldflow3d package)	Apache-2.0 (LICENSE)
Waymo models (waymo-coarse, waymo-refine) + sample maps	Waymo Dataset License — non-commercial (WAYMO_NOTICE.md, https://waymo.com/open/terms)
Front3D models (front3d-coarse, front3d-color)	3D-FRONT terms (non-commercial)
Scenes / meshes / datasets generated with the Waymo models	"Distributed WOD Models" — also non-commercial

The Apache-2.0 license covers the code only; it does not grant rights to the Waymo- or Front3D-derived weights. Using the Waymo models or sample maps means agreeing to the Waymo Open Dataset terms (non-commercial), providing the required attribution, and passing the notice on to downstream recipients. See WAYMO_NOTICE.md and THIRD_PARTY_LICENSES.md.

Supported

• Waymo (map-conditioned) coarse→refine cascade — sequential and simultaneous (feather-averaged) generation.
• Front3D (layout-conditioned) coarse→refine cascade including source-flow + color (unet in=4, with a color mesh sidecar).
• Hub loading via from_hub (subfolder cascade) on both supported stacks (torch 2.2 / diffusers 0.29 and torch 2.5 / diffusers 0.38; NumPy 1.x and 2.x).

Citation

If you use WorldFlow3D in your research, please cite:

@inproceedings{joshi2026worldflow3d,
  title     = {WorldFlow3D: Flowing Through 3D Distributions for Unbounded World Generation},
  author    = {Joshi, Amogh and Ost, Julian and Heide, Felix},
  booktitle = {European Conference on Computer Vision (ECCV)},
  year      = {2026},
}
