laterite

A Rust-backed reader, writer and validator for the AGS4 geotechnical data format. A faster drop-in for python-ags4's AGS4 module — swap from python_ags4 import AGS4 for from laterite import compat as AGS4 — with a narwhals-native API.

Part of the laterite suite

One clean-room Rust AGS4 engine, surfaced for every stack:

Surface	Package	Get it
Python	laterite — PyPI	pip install laterite
Node.js	laterite — npm	npm install laterite
Rust / CLI	lat-db + lat-check	GitHub Releases
Browser	validator + data explorer — WASM	open in a browser

Install

pip install laterite                  # base AGS4 (polars + narwhals)
pip install "laterite[compat]"        # + pandas (python-ags4 drop-in)
pip install "laterite[ags5]"          # + experimental .ags5db surface

Requires Python ≥ 3.12.

Use

import laterite

# Validate a file
result = laterite.validate("delivery.ags")
for rule, findings in result.by_rule().items():
    print(rule, len(findings))

# Or the python-ags4 drop-in
from laterite import compat as AGS4
tables, headings = AGS4.AGS4_to_dataframe("delivery.ags")
AGS4.dataframe_to_AGS4(tables, headings, "round-trip.ags")

# Typed view: PROJ → LOCA → SAMP → ...
from laterite.ags4 import read_typed
proj = read_typed("delivery.ags")
for loca in proj.locas:
    print(loca.loca_id, loca.loca_gl)

lat-check delivery.ags --json

Performance

Validation throughput vs python-ags4 1.2.0, on synthetic AGS4 files of increasing size. Wall-clock after warmup, macOS arm64. All four laterite paths return byte-identical findings to python-ags4 — the speed gain is not at the cost of diagnostic coverage.

The files are LOCA-heavy (40-column real-schema LOCA group, with ID/PA/2DP/DT TYPE columns) generated in two profiles:

Clean — values pre-formatted to match their declared TYPE exactly (2DP rounded to 2 decimals, valid yyyy-mm-dd dates). Real-world files look closer to this. ~15 baseline findings from fixed-cost rules:

Size	python-ags4	laterite.validate	lat-check (CLI)	speedup
512 KB	84 ms	5 ms	10 ms	17×
5 MB	489 ms	57 ms	61 ms	9×
50 MB	5.27 s	0.62 s	0.64 s	8×
500 MB	53.43 s	6.5 s	6.6 s	8×
1 GB	117.27 s	15.1 s	16.5 s	8×

Worst case — same files but with floating-point noise in numeric cells that fails AGS4 Rule 8 (TYPE precision). Every cell triggers a finding; exercises the validator's per-finding accumulation + output-rendering paths fully:

Size	python-ags4	laterite.validate	lat-check (CLI)	Findings	speedup
512 KB	90 ms	7 ms	13 ms	1 129	13×
5 MB	547 ms	67 ms	92 ms	11 485	8×
50 MB	6.09 s	0.79 s	0.96 s	116 415	8×
500 MB	62.45 s	8.1 s	10.1 s	1 170 223	8×
1 GB	132.67 s	18.3 s	22.9 s	2 396 471	7×

Notes on the CLI:

• lat-check --json writes findings to stdout as JSON (~80 bytes/finding). On the worst-case 1 GB file (2.4 M findings) that's ~190 MB of JSON. The native PyO3 path skips this serialisation step — for "validate then process findings in Python", use laterite.validate; for "validate then pipe to downstream tools", use lat-check. On clean files the gap is single-digit %.
• Native PyO3 returns findings as a narwhals frame (rep.findings) or as a Python dict (rep.by_rule()); both pay ~0% extra over the bare validation pass — PyO3's IntoPyObject is well-tuned for our Finding struct.

Both validators scale linearly: ~17 ns/byte for laterite, ~110 ns/byte for python-ags4.

Parity with python-ags4

122 / 131 of python-ags4 1.2.0's own test suite passes through laterite.compat (93 %). The 9 remaining are deliberate non-closures. Full breakdown:

• COMPAT.md — rule-by-rule differences with rationale
• OBSERVATIONS.md — the engineering record (every observation, 5-field house style)
• docs/parity-coverage-map.md — test- level map of laterite ↔ python-ags4

The validator is clean-room: every rule is written from the AGS4 spec, not copied from python-ags4 source. python-ags4 is LGPL-3.0; the clean-room separation lets laterite ship under MIT.

Contributing

See CONTRIBUTING.md. Short version: PRs welcome, CI gates cargo test + pytest + the python-ags4 parity oracle.

License

MIT. The bundled AGS4 standard dictionaries remain © AGS and are redistributed under their published terms.
