Stochastic RT Comparison

This project compares stochastic channel models with ray tracing models using UMAP visualization and machine learning techniques. It includes data generation (Sionna and DeepMIMO), topology analysis (UMAP via cuML), channel compression with autoencoders, and temporal channel prediction models.

Asilomar 2025 Presentation (link)

Install Dependencies

First, install an environment manager. We suggest environment management with conda/mamba, via installation of miniforge.

Second, in each environment, we suggest installing uv.

Third, there will be two environments. One is used for data generation (the one with Tensorflow/Sionna), the other for training models (the one with PyTorch). The reason for this is incompatibilities between TF and PyTorch.

To setup the two environments using the instructions below:

ENV1: sionna environment used for data generation and topology plots with cuML

mamba activate env1_sionna
uv pip install -r env1_sionna.txt

# Install cuML necessary for FAST UMAP transforms (check docs.rapids.ai/install)
uv pip install --extra-index-url=https://pypi.nvidia.com "cuml-cu12==25.4.*"

ENV2: pytorch environment (for training models and experiments)

mamba create -n env2_pytorch python=3.11
mamba activate env2_pytorch

# Install PyTorch to run the models (check pytorch.org/get-started/locally)
pip install torch torchvision --index-url https://download.pytorch.org/whl/cu128

uv pip install -r env2_pytorch env2_pytorch.txt

Usage

Recommended execution: Install jupyter extension in VSCode/Cursor and execute one cell (marked by #%%) at a time.

Important: For data generation, activate the ENV1 (w/ Sionna). For training, activate ENV2 (w/ PyTorch).

(optional) Task 0: Topology

1. Configure data generation parameters in data_gen.py (DataConfig)
2. Generate/load data using load_data_matrices()
3. Visualize data topology using topology/topology.py
4. Train and test compression models via thtt.py

Task 1: Channel Compression

1. Generate data by running thtt_data_gen.py
2. Train and test model with thtt.py

Note: Ensure parameters match between the 2 files.

Task 2: Channel Prediction

1. Run data generation thtt_ch_pred_data_gen.py
2. Run temporal prediction via thtt_ch_pred.py

Note: Ensure parameters match between the 2 files.

Extra Models

We also include 2 transformer models, one for each task:

• TransformerAE for compression
• transformerPred for prediction

These models offer state-of-the-art performance. For the paper we opted for simpler models that are more established in the community mainly because they are faster to train, sometimes by a factor of 10.

Project Structure

Inside ./src/

├── data_gen.py                 # Core data generation and preparation
│   ├── DataConfig              # Configuration class for data generation
│   ├── load_data_matrices()    # Load/generate data for different models
│   ├── prepare_umap_data()     # Prepare data for UMAP analysis
│   └── outlier detection       # Functions for detecting and removing outliers
│
├── sionna_ch_gen.py            # Sionna channel generator wrapper
│
├── topology.py                 # UMAP visualization and analysis
│   ├── Data loading            # Load and prepare data using DataConfig
│   ├── UMAP computation        # Compute UMAP embeddings
│   ├── Visualization           # Plot embeddings with/without outliers
│   └── Partial UMAP fitting    # Fit UMAP on one model, transform another
│
├── topology_utils.py           # Visualization utilities
│   └── plot_umap_embeddings()  # Function for plotting UMAP embeddings
│
├── thtt.py                     # Training and testing (compression)
│   ├── Data preparation        # Prepare data for training
│   ├── Model training          # Train models on different datasets
│   └── Cross-testing           # Test models across different datasets
│
├── thtt_utils.py               # Training utilities
│   ├── convert_channel_angle_delay()  # Convert channel data format
│   └── train_val_test_split()         # Split data for training
│
├── thtt_plot.py                # Plotting utilities for compression experiments
│
├── csinet_train_test.py        # PyTorch training/testing for compression models
│
├── data_feed.py                # PyTorch Dataset for channel matrices
│
├── CsinetPlus.py               # CSI-Net+ baseline model (compression)
│
├── src/
│   └── thtt/
│       ├── compression/
│       │   └── transformerAE.py     # Transformer-based autoencoder
│       └── prediction/
│           └── transformerPred.py   # Transformer for channel prediction
│
├── thtt_ch_pred.py             # Temporal channel prediction experiment (GRU baseline)
│
├── thtt_ch_pred_utils.py       # Utilities for temporal prediction and NMSE matrices
│
├── thtt_ch_pred_plot.py        # Plotting for prediction experiments
│
├── nr_channel_predictor.py     # GRU-based temporal channel predictor
│
├── nr_channel_predictor_wrapper.py  # Train/predict/save/load helpers for GRU predictor
│
├── thtt_ch_pred2.py            # Runner for servers (temporal prediction)
│
├── append_val_losses.py        # Process compression results (thtt) and generate plots
│
├── rt_data_gen_loop.py         # Generate RT data for channel prediction
│
├── ch_compression_results/     # Saved results for compression experiments
│
├── ch_pred_results/            # Saved results for prediction experiments
│
├── nmse_cache/                 # Cached NMSE matrices
│
├── deepmimo_scenarios/         # DeepMIMO scenario metadata (if used)
│
├── slides/                     # Presentation materials
│
└── README.md

Data Flow

data_gen.py
   ├──> topology.py (UMAP visualization)
   │       └──> topology_utils.py (plotting)
   │
   └──> thtt.py (training and testing)
           └──> thtt_utils.py (data preparation)

Key Modules and How They Interact

• data_gen.py

  • Defines DataConfig (generation parameters) and functions like load_data_matrices().
  • Uses SionnaChannelGenerator from sionna_ch_gen.py and DeepMIMO to produce channel matrices.

• sionna_ch_gen.py

  • Provides SionnaChannelGenerator and TopologyConfig used by data_gen.py.

• thtt.py

  • Orchestrates the end-to-end flow: loads pickled matrices, constructs ModelConfig, calls train_models() and cross_test_models() from thtt_utils.py, and plots results.

• model_config.py

  • ModelConfig dataclass centralizes training hyperparameters, dataset directories, and provides get_model_path() helpers for base and fine-tuning scenarios.

• thtt_utils.py

  • Converts channel matrices to angle-delay domain (convert_channel_angle_delay()), performs splits, builds DataLoaders, and calls train_model() from csinet_train_test.py.

• csinet_train_test.py

  • Core PyTorch training: creates DataLoaders using data_feed.DataFeed, computes NMSE, trains either CsinetPlus or TransformerAE depending on config.
  • Imports models:
    • from CsinetPlus import CsinetPlus
    • from transformerAE import TransformerAE (update import path if using src/thtt/compression/transformerAE.py).

• data_feed.py

  • Implements DataFeed PyTorch Dataset. Converts complex channel matrices to real/imag (2, Nc, Nt) format expected by the models.

• CsinetPlus.py

  • CSI-Net+ style autoencoder baseline for channel compression.

• src/thtt/compression/transformerAE.py

  • Implements a transformer-based autoencoder for channel compression.
  • Classes:
    • Encoder: conv + TransformerEncoder over subcarriers, linear projection to encoded_dim.
    • Decoder: linear + TransformerEncoder + conv to reconstruct (2, Nc, Nt).
    • QuantizeLayer: optional differentiable k-bit quantization.
    • TransformerAE: wrapper composing Encoder and Decoder with optional quantization.

• src/thtt/prediction/transformerPred.py

  • Implements a transformer encoder for temporal channel prediction with sequence input (batch, seq_len, input_dim) and final projection to (batch, input_dim).
  • Class:
    • TransformerModel: input projection → TransformerEncoder → flatten → linear head.

• nr_channel_predictor.py and nr_channel_predictor_wrapper.py

  • GRU-based temporal channel predictor and training helpers (construct/train/predict/save/load).

• thtt_ch_pred.py and thtt_ch_pred_utils.py

  • End-to-end temporal prediction experiment logic: generate/process temporal channel H, split sequences, train GRU predictor, compute NMSE matrices across horizons, plot results.

• topology/topology.py and topology/topology_utils.py

  • UMAP embedding computation (optionally with cuML) and visualization helpers.

• append_val_losses.py, thtt_plot.py, thtt_ch_pred_plot.py

  • Plotting/aggregation utilities for experiments.

Call/Usage Map (Selected Paths)

• thtt.py → thtt_utils.py → csinet_train_test.py → {CsinetPlus, TransformerAE} → data_feed.py
• thtt.py → thtt_plot.py (visualization)
• data_gen.py → sionna_ch_gen.py → DeepMIMO/Sionna backends
• thtt_ch_pred.py → nr_channel_predictor_wrapper.py → nr_channel_predictor.py → thtt_ch_pred_utils.py
• topology/topology.py → topology/topology_utils.py

Dependencies

• numpy, scipy
• matplotlib, seaborn
• cuML (for UMAP acceleration - only in topology)
• deepmimo (for ray tracing data)
• sionna (for stochastic channel models)
• torch, torchvision, tqdm, einops

Notes

• GPU acceleration is recommended for both cuML UMAP and PyTorch models.
• Ensure your CUDA version matches the wheels you install for torch and cuML. (acheived through python dependencies)
