A ~46 cm open-source animatronic of Korosuke (コロ助) from Kiteretsu Daihyakka — he sees, listens, thinks, and talks in Japanese or English, emotes through his eyes, waves his arms, and shuts himself down safely. Everything runs 100 % on-device on a D-Robotics RDK X5, with an ESP32-S3 driving the eyes and arms.
🏆 D-Robotics Robotics Dream Keeper Challenge — Stage 3 (Launch) 📄 STAGE3.md — showcase & benchmarks · 🧩 PROPOSAL.md · 🗺 ROADMAP.md
Powered on and left alone, Korosuke wakes and greets you, tracks you with BPU pose
detection, holds a conversation (on-device STT → LLM → TTS, with a "thinking" eye animation
while he ponders), reacts to gestures, waves his arms, and shuts down safely on a button
press (goodnight voice → ✕✕ "safe-to-unplug" eyes). A tabbed web dashboard at
http://<board-ip>:8080 streams the live camera + skeleton and tunes every setting.
| Subsystem | Implementation | Measured |
|---|---|---|
| Vision | BPU YOLO11n-pose (Bayes-e .bin) |
~19.5 FPS |
| Speech-to-text | sherpa-onnx SenseVoice (JP/EN) + Silero VAD | real-time (CPU) |
| LLM dialogue | llama.cpp + TinySwallow-1.5B (Qwen2.5-1.5B-based) — JP & EN personas | 1.5–3.3 tok/s · ~5–10 s/reply |
| Text-to-speech | JP Open JTalk / EN espeak-ng | instant |
| Language | 日本語 / English — STT · LLM · TTS · Web UI, switchable on the fly | on-device |
| Audio out | MAX98357A I2S amp (custom kernel driver) → φ50 speaker | DSP-tuned |
| Eyes | 2× GC9A01 on ESP32-S3 — 8 emotions (smile / thinking / ✕✕) | ≥30 FPS |
| Arms | 2× SG90 rope-pull bellows arms | auto-detach |
🌐 Bilingual & fully on-device. One switch flips the whole robot — speech recognition, LLM replies, voice, and the dashboard — between Japanese and English, with no cloud and no API keys. The voice stack follows D-Robotics' own RDK voice-interaction reference: SenseVoice ASR + a Qwen2.5-1.5B-family LLM (we run the Japanese-tuned TinySwallow-1.5B via llama.cpp on CPU).
| Stage | Theme | What was proven | Doc |
|---|---|---|---|
| 1 — Ideation | On-device perception | YOLO11 vision on the RDK X5 BPU (+ open-source RDK X5 case) | STAGE1.md |
| 2 — Build | System design | The RDK X5 as the single cognitive core under a ROS 2 graph; ESP32s become actuator sub-controllers | PROPOSAL.md |
| 3 — Launch | Shipped robot | The full interactive Korosuke — sees / listens / thinks / talks / emotes, bilingual, 100 % on-device (this repo) | STAGE3.md |
Stage 1's BPU vision is still today's perception layer, and Stage 2's ROS 2 design ships as
ros2_ws/ alongside the low-latency monolith.
All on-device. No cloud, no API keys. Perception on the BPU, dialogue on the CPU.
# 1) Clone
git clone https://github.com/gurimaruking/corosuke-robot.git && cd corosuke-robot
# 2) Flash the eye/arm co-MCU (ESP32-S3) — from the RDK X5 (uses the CH343 UART port)
cd firmware/corosuke_eyes && pio run -t upload && cd ../..
# 3) One-time: MAX98357A I2S amp — build the out-of-tree codec driver + device-tree overlay
# Follow docs/rdk_x5_40pin_i2s_max98357a.md (kernel headers are already on the board)
# 4a) Run the INTEGRATED demo (monolithic, low-latency) as a systemd service
sudo cp deploy/*.service /etc/systemd/system/
sudo systemctl daemon-reload && sudo systemctl enable --now korosuke-monitor korosuke-shutdown-btn
# → open http://<board-ip>:8080 (Monitor / Settings tabs)
# 4b) — or — run the MODULAR ROS 2 graph (same on-device stack: TinySwallow + Open JTalk, no cloud)
cd ros2_ws && colcon build && source install/setup.bash
ros2 launch korosuke_nodes korosuke.launch.py # vision → brain → eyes / dialogue → voice
ros2 launch korosuke_nodes korosuke.launch.py with_web:=true # + rosbridge :9090 → open ros2_ws/src/korosuke_nodes/web/console.html
# NB: eye path is HW-verified; full graph is code-complete but not yet run end-to-end (see STAGE3 §5.1)
# Safe shutdown: hold the GPIO button ~1 s → goodnight voice → ✕✕ eyes → OS halt → cut power.Models (STT / LLM / YOLO .bin) download on the board — see
stt_research.md and dialogue_stack_research.md.
The LLM stays on the CPU by design: the X5 BPU cannot accelerate LLMs
(rdk_x5_bpu_llm.md), so replies take ~5–10 s — the "thinking" eyes
cover the wait.
corosuke-robot/
├── STAGE3.md, PROPOSAL.md, ROADMAP.md # showcase / Stage-2 design / roadmap
├── scripts/ # korosuke_monitor.py (integrated demo) · shutdown_button.py · fix_max98357a.sh
├── ros2_ws/ # ROS 2 graph: korosuke_msgs + korosuke_nodes (vision/brain/dialogue/voice/serial_bridge)
├── firmware/ # ESP32-S3 (PlatformIO): corosuke_eyes (eyes + arms) · max98357a (I2S driver)
├── deploy/ # systemd units + sudoers (auto-start, safe shutdown, audio self-heal)
├── hardware/3d_models/ # OpenSCAD body (color-split) + RDK X5 modular case
└── docs/ # architecture, audio(I2S), BPU-LLM, network, power/USB, research, photos, diary
- STAGE3.md — architecture (Mermaid), benchmarks, known issues & limitations, requirement coverage
- Audio (I2S amp): docs/rdk_x5_40pin_i2s_max98357a.md · firmware/max98357a/
- Why the LLM stays on CPU: docs/rdk_x5_bpu_llm.md
- Network / maintenance: docs/network_setup.md · Power/USB brown-out: docs/power_usb_troubleshooting.md
- Testing: docs/TESTING.md · Build log: docs/diary/
Korosuke's design borrows ideas from these open / animatronic robots:
- Disney's Olaf robot — expressive animatronic eyes & face
- Open Duck Mini (BDX) — compact bipedal droid
- 3D-printed animatronic dual-eye mechanism — the eye-rig approach
MIT for the code/hardware — see LICENSE. Fan-made, non-commercial tribute: "Korosuke" (コロ助) is a character from Kiteretsu Daihyakka by Fujiko F. Fujio; all character rights belong to their respective owners.
「ワガハイはコロ助ナリ！」 🤖
