fix(docx): style PAGE and NUMPAGES fields from their run#458

Merged
developer0hye merged 1 commit into
mainfrom
fix/docx-hf-field-run-style
Jul 25, 2026
Merged

fix(docx): style PAGE and NUMPAGES fields from their run#458
developer0hye merged 1 commit into
mainfrom
fix/docx-hf-field-run-style

Conversation

@developer0hye

Copy link
Copy Markdown
Owner

Summary

  • Carry the containing run's TextStyle on the PAGE and NUMPAGES field IR variants and render the counter under those properties.
  • Word applies the run's properties to a field result; office2pdf fell back to the document default, printing the number at roughly 11 pt black inside an 8 pt gray footer and inflating the line box.

Related issue

Fixes #450

Testing

  • cargo test --workspace (1832 tests, all pass)
  • cargo clippy --workspace --all-targets (clean)
  • cargo fmt --check
  • pdftotext -bbox on the page-1 footer of 05_technical_manual_en against the Word PDF
  • pdftoppm -r 150 plus a 300% crop of the footer line
  • magick compare -metric AE -fuzz 5% on the size-normalized page

Page-1 footer glyph boxes:

Glyph Word GT before after
- literal 797.55-806.40 800.68-808.18 798.99-806.50
1 field 797.55-806.40 796.67-809.21 798.99-806.50

In Word every glyph on the footer line shares one box. Before the fix the field's box was 12.54 pt against the literals' 7.51 pt; after, all three match.

Visual impact

  • No rendered PDF change
  • Rendered PDF change or visual evidence added
  • Reason:

Visual audit

  • Issue: DOCX: PAGE and NUMPAGES fields in headers/footers lose their run formatting #450
  • Fixture: tests/golden_mocks/business/sources/docx/05_technical_manual_en.docx
  • Page(s): 1 (page 2 carries the same footer and was also checked)
  • Renderer and DPI: pdftoppm, 150 DPI
  • Evidence mode: fix
  • New follow-up issues found in this audit: None
  • GT: assets/bugfixes/issue-450/gt.jpg
  • Before: assets/bugfixes/issue-450/before.jpg
  • After: assets/bugfixes/issue-450/after.jpg

Visual comparison

GT Before After
GT Before After

Required inspection

  • Rendered all evidence at 150 DPI or higher
  • Stored progressive JPEG quality 86 assets with metadata stripped
  • Inspected matched region crops at full resolution
  • Ran the 5% fuzz pixel-difference sweep
  • Inventoried hairlines and border dash styles
  • Inventoried font weight, italic, and underline emphasis

Deviation audit

Check Result
Page count/order Matches GT: two pages in the same order
Element presence Matches GT: header, header rule, headings, code blocks, and footer are all present
Position/size Fixed: the footer field now shares the literals' line box instead of standing 5 pt taller
Rotation/flip No deviation observed
Fill Matches GT: the F4F4F4 code-block shading is present
Stroke/border Matches GT: the 0.5 pt CCCCCC header rule is present at its w:space offset
Text content Matches GT
Font family/weight/style Fixed: the page number renders at the run's 8 pt instead of the document default
Text color Fixed: the page number renders in the run's 888888 instead of black
Alignment Matches GT: the footer stays centered
Line/paragraph spacing Remaining: #452 tracks consecutive Courier New paragraphs advancing tighter than Word
Clipping/overflow No deviation observed

Checklist

  • Commits include a Signed-off-by line
  • PR scope contains one root cause
  • Remaining visual deviations each reference an open issue

Word applies the containing run's properties to a field result, so a
footer written as an 8 pt gray run with a `PAGE` field prints the number
at 8 pt gray. office2pdf dropped the run properties and fell back to the
document default, printing the number at roughly 11 pt black and
inflating the footer's line box.

Carry the run's `TextStyle` on the field IR variants and emit the counter
under those properties.

Fixes #450

Signed-off-by: Yonghye Kwon <developer.0hye@gmail.com>
@developer0hye
developer0hye merged commit 581edaa into main Jul 25, 2026
17 checks passed
@developer0hye
developer0hye deleted the fix/docx-hf-field-run-style branch July 25, 2026 11:45
