FlowMap

Cross-repo code intelligence CLI for LLMs.

One query. Cross-repo. Polyglot. Ranked by relevance.

Quick Start • Features • Examples • Commands • Docs

See it in action

One query. Cross-repo. Polyglot. Ranked by relevance.

Why?

You have 5 repos. You know the retry logic exists somewhere. With grep you'd need to search each repo, wade through hundreds of string matches, and hope you find the right function. With FlowMap:

$ flowmap search "retry logic with exponential backoff"
[1] api-gateway/src/utils/retry.ts:12-45  (rrf: 0.0312, via: ripgrep+semantic)
    export async function withRetry<T>(fn: () => Promise<T>, opts: RetryOptions): Promise<T> { ...

[2] payment-service/src/http/client.py:88-120  (rrf: 0.0198, via: semantic+symbol)
    def retry_with_backoff(func: Callable, max_retries: int = 3, base_delay: float = 1.0): ...

[3] shared-lib/pkg/resilience/retry.go:15-52  (rrf: 0.0147, via: semantic)
    func Retry(ctx context.Context, fn func() error, opts ...Option) error { ...

That's the point. Hybrid search fuses ripgrep, BM25/FTS, vector similarity, and symbol lookup into one ranked result — semantic understanding, not just string matching.

Features

Feature	What it does
AST-aware indexing	Tree-sitter extracts functions, classes, methods, and signatures — not raw text
Hybrid search	4 channels fused via Reciprocal Rank Fusion: ripgrep, BM25/FTS, vector similarity, symbol lookup
Incremental reindexing	`git diff` → only re-embeds changed files (seconds, not minutes)
Structural history	AST-level diffs over time: "function `processPayment` had its signature changed on March 3rd"
Cross-repo by default	One query, all your projects — no `--repo` flag needed
Local-first	Embeddings via Ollama, storage via LanceDB + SQLite — no cloud, no API keys, no telemetry
JSON output everywhere	`--format json` on every command for piping into LLMs
Crash recovery	Interrupted indexing resumes cleanly; no half-indexed state

Quick start

# 1. Install FlowMap (uv is the fastest path)
git clone https://github.com/aniketcodes/flowmap-cli.git
cd flowmap-cli
uv tool install .

# 2. Install Ollama (free, local embeddings)
brew install ollama                              # macOS
# Linux:   curl -fsSL https://ollama.com/install.sh | sh
# Windows: download from https://ollama.com/download
ollama serve
ollama pull qwen3-embedding:0.6b

# 3. Install ripgrep (for keyword search)
brew install ripgrep                             # macOS
# Ubuntu/Debian: apt install ripgrep

# 4. Add your repos and index
flowmap init
flowmap repos add /path/to/your/project
flowmap index

# 5. Search
flowmap search "retry logic"

That's it. First index takes a few minutes depending on repo size; subsequent runs are incremental (seconds).

Alternative: without global install

uv sync
uv run flowmap search "retry logic"

Real-world workflows

"I just joined a new team. How is this codebase structured?"

flowmap repos add /path/to/the/repo
flowmap index
flowmap map

Every class, function, and file at a glance — across all repos.

"Where is the code that does X?"

flowmap search "payment processing"
flowmap search "retry logic"
flowmap search "database connection pool"

The core use case. Describe what you're looking for in plain English; FlowMap finds the relevant functions/classes across all your repos.

"I know the function name but not which repo it's in"

flowmap search "processOrder" --mode symbol

Exact/fuzzy match on function and class names. Instant, no embeddings needed.

"I found a function. Show me the full source."

flowmap cat src/auth.py --repo auth-service --lines 25-70
flowmap cat src/auth.py --repo auth-service --symbol validateToken

"What changed in this area of the code recently?"

flowmap history "validateToken"
flowmap history "payment" --repo payment-service --since "3 months ago"

AST-level diffs — not just "file changed" but "function processPayment had its signature changed on March 3rd."

"I need to give an LLM context about my codebase"

flowmap map --format json
flowmap search "how does auth work" --format json
flowmap cat src/auth.py --repo my-service --format json

All commands support --format json. Pipe them to Claude, ChatGPT, or any LLM tool.

"I pulled from git. Update the index."

flowmap index

Detects what changed via git diff and only re-embeds the modified files. Takes seconds.

"Something is broken. How do I debug?"

flowmap doctor

Checks: Ollama running? Model pulled? Repos exist? Index healthy? Dimension mismatch? Tells you exactly what's wrong.

"I want fast grep-style search without Ollama"

flowmap search "TODO" --mode keyword

Uses ripgrep directly. No embeddings, instant results.

Cheat sheet

flowmap index                    # Build/update the index (incremental)
flowmap index --full             # Force full rebuild
flowmap search "query"           # Hybrid search (semantic + BM25 + keyword + symbol)
flowmap search "fn" --mode symbol  # Find by function/class name
flowmap search "x" --mode keyword  # Grep-style (no Ollama needed)
flowmap map                      # Show repo structure
flowmap symbols                  # List all functions/classes
flowmap symbols "auth"           # Search symbols by name
flowmap cat file.py --repo R     # Read a file
flowmap cat file.py --symbol fn  # Jump to a symbol
flowmap history "query"          # Show structural changes over time
flowmap status                   # Check index health
flowmap doctor                   # Full system health check
flowmap repos add /path          # Add a repo
flowmap repos list               # List configured repos
flowmap reset --all              # Delete all index data

Commands

flowmap search — the main command

# Default: hybrid search (semantic + BM25 + keyword + symbol fusion)
flowmap search "database connection pooling"

# Semantic only (vector similarity)
flowmap search "error handling patterns" --mode semantic

# Keyword only (ripgrep -- no embeddings needed)
flowmap search "TODO" --mode keyword

# Symbol lookup (exact/fuzzy match on function/class names)
flowmap search "AuthMiddleware" --mode symbol

# Filter to one repo
flowmap search "validateToken" --repo auth-service

# JSON output (for piping to LLMs)
flowmap search "payment processing" --format json

# Cross-encoder reranking (slower but higher quality)
flowmap search "complex query" --rerank

Search modes:

Mode	What it does	Speed	Needs Ollama?
`hybrid` (default)	Fuses ripgrep + BM25/FTS + vector + symbol via RRF	~1-2s	Yes
`semantic`	Vector similarity only	~0.5s	Yes
`keyword`	ripgrep only (live filesystem grep)	~0.1s	No
`symbol`	Exact/suffix/contains match on symbol names	~0.1s	No

flowmap index — build or update the search index

flowmap index                    # Index all repos (incremental)
flowmap index --full             # Force full re-index
flowmap index --repo my-service  # Index a specific repo
flowmap index --dry-run          # Preview what would be indexed

flowmap map — structural overview of repos

flowmap map
flowmap map --repo my-service
flowmap map --format json

flowmap symbols — list/search symbols

flowmap symbols                              # All symbols
flowmap symbols "process"                    # Search by name
flowmap symbols --type class                 # Filter by type
flowmap symbols --type function --repo my-service
flowmap symbols "validate" --format json

flowmap cat — read source files

flowmap cat my-service/src/auth.py                              # Auto-detect repo
flowmap cat src/auth.py --repo my-service --lines 25-70
flowmap cat src/auth.py --repo my-service --symbol validateToken
flowmap cat src/service.ts --repo my-service --format json

flowmap history — structural change timeline

flowmap history "validateToken"
flowmap history "payment" --repo payment-service --since "3 months ago"
flowmap history "OrderProcessor" --symbol OrderProcessor.process
flowmap history "auth" --format json

flowmap status — index health

flowmap status

Index: 12,450 total chunks
  my-service                      4,230 chunks  2026-04-01  (main, abc1234)
  auth-service                    3,100 chunks  2026-04-01  (main, def5678)
  shared-lib                      5,120 chunks  2026-03-28  (main, 789abcd)

flowmap doctor — system health check

flowmap doctor

Checks: repo paths exist, Ollama is running, embedding model is pulled, ripgrep is installed, index is healthy, no dimension mismatches.

flowmap repos — manage configured repositories

flowmap repos add /path/to/repo          # Add a repo
flowmap repos add /path/to/repo --name custom-name
flowmap repos list
flowmap repos paths                      # One path per line

flowmap reset — delete index data

flowmap reset --repo my-service    # Reset one repo
flowmap reset --all                # Reset everything

flowmap init — create a starter config file

flowmap init                # Creates ~/.flowmap/config.yaml
flowmap init --force        # Overwrite existing config (preserves repo list)

Languages with AST support

Tier	Languages
Full AST (functions, classes, methods, signatures)	Python • TypeScript • JavaScript • TSX/JSX • Go • Java • Swift • Rust
Structural (top-level keys)	YAML • JSON
Fallback (line-based, no symbol extraction)	C • C++ • Kotlin • Ruby • PHP • C# • SQL • GraphQL • Protobuf • Terraform • Shell • Markdown

Configuration

Config lives at ~/.flowmap/config.yaml. Created by flowmap init.

# FlowMap configuration

repos:
  - name: my-service
    path: /Users/you/code/my-service
  - name: auth-service
    path: /Users/you/code/auth-service

data_dir: ~/.flowmap/data

embedding:
  backend: ollama                        # ollama | sentence-transformers
  model: qwen3-embedding:0.6b           # model name
  ollama_url: http://localhost:11434

reranking:
  enabled: false                         # Enable with --rerank flag instead
  model: cross-encoder/ms-marco-MiniLM-L-6-v2

Custom config path

flowmap --config /path/to/config.yaml search "query"

`.flowmapignore`

Add a .flowmapignore file to any repo root to exclude files from indexing. Uses gitignore syntax.

# .flowmapignore
generated/
*.pb.go
*_test.go
vendor/

Embedding backends

Ollama (default, recommended)

Free, local, no API keys. Runs on CPU or GPU.

ollama serve
ollama pull qwen3-embedding:0.6b

embedding:
  backend: ollama
  model: qwen3-embedding:0.6b
  ollama_url: http://localhost:11434

Sentence-transformers (optional)

Local Python-based embeddings. No external server needed, but requires PyTorch.

uv tool install ".[local-embeddings]"
# Or, in a cloned repo:
uv sync --extra local-embeddings

embedding:
  backend: sentence-transformers
  model: nomic-ai/CodeRankEmbed

How it works

Your repos                FlowMap                    Search
-----------              ---------                  --------
  .py .ts .go    --->   tree-sitter AST parsing
  .java .yaml            chunk into functions,
                          classes, methods
                              |
                              v
                         Ollama / sentence-transformers
                          generate embeddings
                              |
                              v
                         LanceDB (vectors)  +  SQLite (metadata)
                          local storage, no cloud
                              |
                              v
                         4-way hybrid search  <---  "your query"
                          ripgrep + vector + symbol
                              |
                              v
                         Reciprocal Rank Fusion
                          merge & score results
                              |
                              v
                         Ranked results with
                          file, line, symbol, score

Indexing pipeline:

Walk repos via git ls-files (respects .gitignore)
Parse each file with tree-sitter to extract functions, classes, methods
Generate embeddings via Ollama (batched, with retry)
Store in LanceDB (vectors) + SQLite (metadata, state tracking)
Incremental updates via git diff — only changed files are re-embedded

Search pipeline:

Classify query (identifier vs natural language vs mixed)
Run 3 search channels in parallel: ripgrep, vector similarity, symbol lookup
Map ripgrep line hits to stored chunks (dedup before scoring)
Fuse with weighted Reciprocal Rank Fusion (weights based on query type)
Optional cross-encoder reranking on top-30 candidates

JSON output

All commands support --format json for piping to LLMs or scripts:

# Feed search results to an LLM
flowmap search "auth middleware" --format json | llm "explain these results"

# Get repo map as structured data
flowmap map --format json | jq '.repos[].classes[].name'

# Read a file for LLM context
flowmap cat src/auth.py --repo my-service --format json

Troubleshooting

flowmap doctor reports issues

Run flowmap doctor first. It checks everything and tells you what's wrong.

"Ollama not running"

ollama serve          # Start Ollama
ollama pull qwen3-embedding:0.6b   # Pull the model

"ripgrep (rg) not installed"

Keyword search and hybrid mode need ripgrep. Install it:

brew install ripgrep   # macOS
apt install ripgrep    # Ubuntu/Debian

Without ripgrep, --mode semantic and --mode symbol still work.

"Dimension mismatch"

You changed the embedding model after indexing. Fix:

flowmap index --full

Search returns no results

flowmap status        # Check if repos are indexed
flowmap index         # Re-index if needed
flowmap doctor        # Check system health

Slow indexing

First index is slow (parses all files + generates embeddings). Subsequent runs are incremental and fast. For very large repos, ensure Ollama has enough resources:

# Check Ollama is responsive
curl http://localhost:11434/api/tags

Requirements

Tool	Purpose
Python `>= 3.11`	Runtime
Ollama	Embedding generation — install
ripgrep	Keyword search — install
git	File listing and incremental reindex

Development

# Clone
git clone https://github.com/aniketcodes/flowmap-cli.git
cd flowmap-cli

# Install with dev dependencies
uv sync --extra dev

# Run tests
uv run pytest tests/ -v

# Lint
uv run ruff check flowmap/

Test suite

424 tests covering:

Tree-sitter chunking (Python, TypeScript, Go, Java, YAML, JSON)
LanceDB store operations (real database, not mocked)
CLI commands (all 11 commands)
Hybrid search fusion and deduplication
Incremental reindexing with git
End-to-end: index → search → cat pipeline
SQL escaping and special character handling
Crash recovery (embedding failure preserves data)
History/timeline with structural diffs

FAQ

How is this different from grep / ripgrep?

ripgrep finds literal text matches. FlowMap understands code structure — it knows what a function is, what class it belongs to, and can find semantically similar code even when the exact words don't match. FlowMap actually uses ripgrep as one of its three search channels and fuses the results.

How is this different from GitHub code search?

GitHub code search works on github.com. FlowMap works on your local repos, offline, with no data leaving your machine. It also searches across multiple repos at once and provides structural history (AST-level diffs over time).

Does my code leave my machine?

No. Everything runs locally. Embeddings are generated by Ollama on your machine. Data is stored in ~/.flowmap/data. No cloud services, no API keys, no telemetry.

How much disk space does it use?

Roughly 1-2 MB per 1,000 source files. A 10-repo setup with 50K files typically uses ~100 MB for the LanceDB vector store.

Can I use OpenAI / Anthropic / other API embeddings?

Not currently. FlowMap supports Ollama (recommended) and sentence-transformers. Adding API-based backends is straightforward if there's demand — open an issue.

How long does indexing take?

First full index: ~1-5 minutes for a typical repo (depends on size and Ollama speed). Incremental updates after git pull: seconds — only changed files are re-embedded.

Can I use this with Claude Code / Cursor / Copilot?

Yes. Use --format json to pipe structured results into any LLM tool:

flowmap search "auth middleware" --format json
flowmap cat src/auth.py --repo my-service --format json
flowmap map --format json

What if Ollama is too slow?

Use a GPU-accelerated Ollama install for faster embeddings
Use --mode keyword or --mode symbol for searches that don't need embeddings
The default model (qwen3-embedding:0.6b) is small and fast — larger models are more accurate but slower

Can I add support for a new language?

If tree-sitter has a grammar for your language, yes. Add the grammar package to pyproject.toml, register the extension mapping in flowmap/parsing/languages.py, and define symbol extraction rules in flowmap/parsing/chunker.py. PRs welcome.

Contributing

Contributions are welcome. Here's how to get started:

Setup

git clone https://github.com/aniketcodes/flowmap-cli.git
cd flowmap-cli
uv sync --extra dev

Run tests before changing anything

uv run pytest tests/ -v

All 424 tests should pass. If they don't, your environment has an issue — fix that first.

Making changes

Create a branch from master
Write your code — follow the existing style (4-space indent, no docstrings on obvious functions, no unnecessary abstractions)
Add tests for any new behavior — look at existing tests for patterns
Run the full test suite — uv run pytest tests/ -v
Lint — uv run ruff check flowmap/
Open a PR with a clear description of what and why

What makes a good PR

Bug fixes with a test that would have caught the bug
New tree-sitter language grammars (Python, TS, Go, Java, Swift, Rust are done — C, C++, Ruby are not)
Performance improvements with before/after measurements
Better error messages for common failure modes

What to avoid

Don't add features nobody asked for — open an issue first to discuss
Don't refactor working code for style preferences
Don't add dependencies without a strong reason
Don't break the --format json contract (other tools depend on it)

Project structure

flowmap/
  cli.py                  # Click commands (entry point)
  config.py               # YAML config loading, defaults
  store.py                # LanceDB vector store
  state.py                # SQLite metadata (indexed SHAs, pending markers)
  embeddings.py           # Ollama + sentence-transformers backends
  indexer.py              # File walking, chunking orchestration
  reindex.py              # Incremental reindex via git diff
  render.py               # Output formatting (text + JSON)
  parsing/
    chunker.py            # Tree-sitter AST chunking
    languages.py          # Grammar registry
  search/
    hybrid.py             # 4-way fusion + RRF + reranking
    ripgrep.py            # ripgrep subprocess wrapper
  services/
    indexing.py            # Index orchestration (full + incremental)
    file_resolver.py       # Resolve file paths across repos
    symbol_lookup.py       # Symbol resolution for --symbol flag
    map_builder.py         # Structural map data builder
  history/
    timeline.py            # Temporal query orchestration
    structural_diff.py     # AST-level diffing between versions
    git_ops.py             # Git log, show, pickaxe wrappers
tests/
  conftest.py              # Shared fixtures (MockBackend, hash_vector)
  test_chunker.py          # 77 tests -- AST parsing for all languages
  test_store_integration.py # 43 tests -- real LanceDB operations
  test_cli_commands.py     # 33 tests -- all CLI commands
  test_end_to_end.py       # 10 tests -- full index->search pipeline
  test_reindex.py          # 18 tests -- incremental reindex + ordering
  test_history.py          # 24 tests -- git ops + structural diff
  ...and more (424 total)

Known limitations

Large repos (>50K files): Memory usage scales with repo size. The entire chunk + embedding set is held in memory during indexing. For very large monorepos, ensure adequate RAM.
Windows: Best-effort support. The advisory file lock behavior differs from Unix. Primary development and testing is on macOS/Linux.
AST coverage: Only Python, TypeScript, JavaScript, Go, Java, Swift, Rust, YAML, and JSON have full tree-sitter grammars. Other languages fall back to line-based chunking (still indexed, but no symbol extraction).
Concurrent access: Designed for single-user CLI use. Don't run flowmap index from multiple terminals simultaneously. Search during indexing may return partial results.

For AI agents

This section helps AI coding assistants (Claude Code, Cursor, Copilot, Aider, etc.) discover and use FlowMap when it's available on the user's machine.

What is FlowMap?

FlowMap is a CLI tool installed on this machine that provides cross-repo code search. If the user has configured repos with FlowMap, you can use it to find code faster than reading files manually.

How to check if FlowMap is available

flowmap --help        # Check if installed
flowmap status        # Check if repos are indexed
flowmap doctor        # Full health check

How to use FlowMap for code search

# Find code by meaning (semantic + BM25 + keyword + symbol fusion)
flowmap search "authentication middleware" --format json

# Find a specific function or class by name
flowmap search "processOrder" --mode symbol --format json

# Grep-style keyword search (no embeddings needed)
flowmap search "TODO" --mode keyword --format json

# Get structural overview of all indexed repos
flowmap map --format json

# Read a specific file with line numbers
flowmap cat src/auth.py --repo my-service --format json

# Jump to a specific symbol's source code
flowmap cat src/auth.py --repo my-service --symbol validateToken --format json

# See what functions changed recently
flowmap history "validateToken" --format json

When to use FlowMap vs reading files directly

Scenario	Use FlowMap	Use file reads
"Where is the retry logic?"	`flowmap search "retry logic"`	-
"What does `processOrder` do?"	`flowmap search "processOrder" --mode symbol`	Then `flowmap cat` the result
"Show me all classes in the project"	`flowmap symbols --type class`	-
"Read lines 50-100 of auth.py"	-	Read the file directly
"What changed in auth recently?"	`flowmap history "auth"`	-

Tips

Always use --format json when calling FlowMap — it gives structured output you can parse
flowmap search returns results ranked by relevance — the first result is usually the best
If flowmap status shows "not indexed", the user needs to run flowmap index first
FlowMap searches across ALL configured repos at once — you don't need to know which repo a function is in

License

MIT

Name		Name	Last commit message	Last commit date
flowmap		flowmap
tests		tests
.gitignore		.gitignore
LICENSE		LICENSE
README.md		README.md
pyproject.toml		pyproject.toml
requirements.txt		requirements.txt
uv.lock		uv.lock

Latest commit

History

Folders and files

Repository files navigation
