🛡️ VIGIL

A real-time desktop monitoring platform for system performance, security events, intelligent alerting, and cloud synchronization.

📌 About

VIGIL is a desktop-based system monitoring and security observability platform designed to provide real-time visibility into machine health, performance, security activity, and operational alerts.

It continuously collects system telemetry such as:

CPU utilization
Memory utilization
Disk activity and storage usage
Network traffic
Running processes
System uptime
Load averages
File-system activity
Authentication-related events
Process activity

VIGIL combines this information with an alert management and correlation engine, allowing multiple events to be analyzed and consolidated into meaningful alerts instead of simply displaying raw telemetry.

The platform also supports encrypted cloud synchronization through Supabase, allowing monitoring data and alerts to be synchronized beyond the local machine while maintaining configurable privacy controls and an offline synchronization queue.

✨ Key Features

📊 Real-Time System Monitoring

Monitor the health and performance of the machine in real time.

CPU utilization
Per-core CPU information
RAM usage
Disk usage
Disk read/write activity
Network upload/download activity
Running process information
Process CPU and memory consumption
System uptime
Load averages
Historical metric tracking

🛡️ Security Event Monitoring

VIGIL provides security-oriented event monitoring in addition to traditional performance monitoring.

Supported monitoring includes:

File-system activity
Authentication events
Process activity
Security event logging
Event severity classification
Event searching
Recent event history
Security-event statistics

Security events can automatically flow into the alert management system.

🚨 Intelligent Alert Management

VIGIL includes a dedicated alert-management subsystem instead of treating every threshold violation as an independent notification.

Alerts support:

Capability	Description
Severity	INFO, LOW, MEDIUM, HIGH, CRITICAL
Categories	Performance, Security, System, Correlation
Status	New, Acknowledged, Resolved, Suppressed
Deduplication	Detects duplicate alerts
Suppression	Suppresses matching alert conditions
Escalation	Escalates important unresolved alerts
Correlation	Combines related events
Acknowledgement	Allows operators to acknowledge alerts
Resolution	Tracks resolved alerts
History	Maintains alert history and statistics

🔗 Event Correlation

Rather than overwhelming the operator with individual events, VIGIL can correlate related alerts and generate higher-level correlated alerts.

This is particularly useful when multiple symptoms originate from the same underlying condition.

For example:

High CPU
   ↓
Process consuming excessive resources
   ↓
System performance degradation
   ↓
Related alerts correlated
   ↓
Single meaningful incident

☁️ Cloud Synchronization

VIGIL integrates with Supabase/PostgreSQL for cloud-based data synchronization.

Cloud synchronization supports:

Machine registration
System metrics
Security events
Alerts
Offline synchronization queue
Batch synchronization
Sync status tracking
Sync history
Machine health/status information
Configurable privacy levels

If the cloud connection is temporarily unavailable, data can remain queued locally and synchronized later.

🔐 Privacy & Encryption

Sensitive information can be protected before being synchronized to the cloud.

VIGIL includes:

Encryption support
Configurable privacy levels
Sensitive-data filtering
Data hashing
Environment-based secret management
Local/cloud separation
Configurable data retention

Secrets such as Supabase credentials are intended to be supplied through environment variables rather than committed directly to source control.

📈 Live Data Visualization

The desktop dashboard provides visual representations of system activity.

Live graphs can display:

CPU usage
Memory usage
Disk activity
Network activity
Historical system metrics

Graphs dynamically update as new monitoring data is collected.

📤 Data Export

The project includes an export subsystem for working with collected monitoring information and generating data suitable for further analysis.

The project also includes Pandas-based data processing support.

🏗️ Architecture

VIGIL follows a modular architecture separating monitoring, security, alert processing, synchronization, configuration, and presentation.

┌─────────────────────────────────────────────┐
│              VIGIL Desktop UI               │
│                                             │
│  Dashboard │ Graphs │ Processes │ Alerts   │
└──────────────────────┬──────────────────────┘
                       │
                       ▼
┌─────────────────────────────────────────────┐
│             Core Monitoring Layer           │
│                                             │
│  SystemMonitor                              │
│  SecurityLogger                             │
│  AlertManager                               │
│  Correlation Engine                         │
└──────────────────────┬──────────────────────┘
                       │
              ┌────────┴────────┐
              ▼                 ▼
┌─────────────────────┐  ┌───────────────────┐
│ Local Data / Queue  │  │ Security & Crypto │
│                     │  │                   │
│ SQLite / Local DB   │  │ Encryption        │
│ Sync Queue          │  │ Privacy Filtering │
└──────────┬──────────┘  └───────────────────┘
           │
           ▼
┌─────────────────────────────────────────────┐
│              CloudSync Layer                │
│                                             │
│        Supabase PostgreSQL Backend          │
└─────────────────────────────────────────────┘

Core Components

main.py
   │
   ├── ConfigManager
   │
   ├── SystemMonitor
   │      ├── CPU
   │      ├── Memory
   │      ├── Disk
   │      ├── Network
   │      └── Processes
   │
   ├── SecurityLogger
   │      ├── File Monitoring
   │      ├── Authentication Monitoring
   │      └── Process Monitoring
   │
   ├── AlertManager
   │      ├── Deduplication
   │      ├── Suppression
   │      ├── Escalation
   │      └── Correlation
   │
   ├── CloudSync
   │      ├── Privacy Filtering
   │      ├── Encryption
   │      ├── Offline Queue
   │      └── Supabase Synchronization
   │
   └── VigilDashboard
          ├── Metrics
          ├── Graphs
          ├── Processes
          └── Alerts

🧰 Technology Stack

Core

Python 3.10+
PySimpleGUI — Desktop user interface
PyYAML — Configuration management
psutil — System and process monitoring
watchdog — File-system monitoring

Data & Visualization

Pandas — Data processing and export
Matplotlib — Live monitoring graphs

Cloud

Supabase
PostgreSQL
aiohttp — Asynchronous HTTP communication

Security

cryptography — Encryption
python-dotenv — Secure environment configuration

Development

pytest
pytest-asyncio
Black
Pylint
MyPy
pre-commit

📁 Project Structure

vigil/
│
├── main.py
├── config.yaml
├── requirements.txt
├── .env.template
│
├── src/
│   │
│   ├── core/
│   │   ├── alert_manager.py
│   │   ├── cloud_sync.py
│   │   ├── config_manager.py
│   │   ├── correlation_engine.py
│   │   ├── encryption.py
│   │   ├── export_manager.py
│   │   ├── security_logger.py
│   │   ├── supabase_client.py
│   │   └── system_monitor.py
│   │
│   ├── ui/
│   │   ├── dashboard.py
│   │   ├── themes.py
│   │   └── components/
│   │
│   ├── utils/
│   │   ├── diagnostic.py
│   │   ├── encryption.py
│   │   ├── helpers.py
│   │   └── logging.py
│   │
│   └── config/
│       └── default_config.yaml
│
├── scripts/
│   ├── install.sh
│   ├── setup_supabase.py
│   ├── diagnose.sh
│   └── vigil.service
│
├── tests/
│   ├── test_integration.py
│   ├── test_unit_system_monitor.py
│   ├── test_unit_supabase_client.py
│   ├── test_system_monitor_basic.py
│   └── diagnostic.py
│
└── assets/

🚀 Getting Started

1. Clone the Repository

git clone https://github.com/your-username/vigil.git
cd vigil

2. Create a Virtual Environment

python -m venv venv

Activate it:

Linux / macOS

source venv/bin/activate

Windows

venv\Scripts\activate

3. Install Dependencies

pip install -r requirements.txt

⚙️ Configuration

Create your environment file from the provided template:

cp .env.template .env

Then configure your Supabase credentials:

SUPABASE_URL=https://your-project.supabase.co
SUPABASE_SERVICE_KEY=your-service-role-key

MACHINE_NAME=
ENCRYPTION_KEY=

LOG_LEVEL=INFO
DATA_RETENTION_DAYS=30

Environment Variables

Variable	Purpose
`SUPABASE_URL`	Supabase project URL
`SUPABASE_SERVICE_KEY`	Supabase service-role/API credential
`MACHINE_NAME`	Custom machine identifier
`ENCRYPTION_KEY`	Encryption key
`LOG_LEVEL`	Application logging level
`DATA_RETENTION_DAYS`	Metric retention period

Important: Never commit .env or production Supabase credentials to GitHub.

🗄️ Supabase Setup

The repository contains the database schema required by VIGIL:

src/core/supabase_schema.sql

The schema provides tables for:

machines
    │
    ├── system_metrics
    │
    ├── security_events
    │
    └── alerts

sync_queue

It also includes:

Indexes
Row-Level Security policies
Database functions
Update triggers
Machine-status helpers
Metric cleanup functionality
Latest-metric views

Run the schema in your Supabase PostgreSQL SQL editor before enabling cloud synchronization.

▶️ Running VIGIL

Start the application with:

python main.py

The application initializes:

Configuration
      ↓
Alert Manager
      ↓
System Monitor
      ↓
Security Logger
      ↓
Cloud Sync
      ↓
Desktop Dashboard

Once running, VIGIL begins collecting system telemetry and monitoring configured security events.

🧪 Testing

Run the complete test suite using:

pytest

Run a specific test:

pytest tests/test_unit_system_monitor.py

Integration tests:

pytest tests/test_integration.py

The repository also contains diagnostic utilities for troubleshooting installation and runtime issues.

🩺 Diagnostics

For Linux environments, the project provides:

./scripts/diagnose.sh

Installation helper:

./scripts/install.sh

A systemd service definition is also included:

scripts/vigil.service

This allows VIGIL to be configured as a background Linux service.

🔄 Monitoring Pipeline

VIGIL's monitoring pipeline can be summarized as:

Operating System
       │
       ▼
   psutil / watchdog
       │
       ▼
 SystemMonitor ───────────────┐
       │                      │
       │                      ▼
       │                CloudSync Queue
       │                      │
       ▼                      │
 AlertManager                 │
       │                      │
       ├── Deduplication      │
       ├── Suppression        │
       ├── Escalation         │
       └── Correlation        │
       │                      │
       ▼                      │
 SecurityLogger ──────────────┤
       │                      │
       ▼                      ▼
   Dashboard             Supabase
                              │
                              ▼
                         PostgreSQL

🔐 Security Model

VIGIL is designed around several security principles:

Secrets

Credentials are loaded from environment variables rather than hard-coded configuration.

Encryption

Sensitive information can be encrypted before cloud synchronization.

Privacy Filtering

Cloud synchronization supports configurable privacy levels to determine what information should be synchronized.

Hash Verification

Security events can contain hashes that help verify data integrity.

Row-Level Security

The Supabase schema enables PostgreSQL Row-Level Security policies for application tables.

📊 Database Model

The primary cloud data model contains:

`machines`

Stores registered monitoring machines and their current status.

`system_metrics`

Stores CPU, memory, disk, network, process, and load information.

`security_events`

Stores security-related events such as file, authentication, and process activity.

`alerts`

Stores generated and correlated alerts with severity and lifecycle state.

`sync_queue`

Provides reliable synchronization when cloud connectivity is unavailable.

🎯 Design Goals

VIGIL was designed around five primary goals:

1. Visibility

Provide a single interface for understanding system health and security activity.

2. Responsiveness

Collect and display live telemetry without blocking the user interface.

3. Reliability

Continue collecting information even when cloud connectivity is unavailable.

4. Security

Protect sensitive monitoring information through encryption and privacy controls.

5. Extensibility

Maintain a modular architecture so additional monitors, alert types, data sources, and cloud integrations can be added independently.

🛠️ Development

The project separates responsibilities into independent modules:

Core
 ├── Monitoring
 ├── Security
 ├── Alerting
 ├── Correlation
 ├── Synchronization
 ├── Encryption
 └── Configuration

UI
 ├── Dashboard
 ├── Themes
 └── Components

Utils
 ├── Logging
 ├── Diagnostics
 ├── Helpers
 └── Encryption

This separation makes the project easier to test, maintain, and extend.

🔮 Future Improvements

Potential areas for future development include:

Multi-machine centralized monitoring
Web-based management dashboard
Advanced anomaly detection
Machine-learning-based threat detection
More security event sources
Role-based access control
Real-time cloud notifications
Email/Slack/Discord alert integrations
Advanced incident timelines
Container and server monitoring
Expanded Windows/macOS security telemetry
More granular Supabase authorization policies

⚠️ Disclaimer

VIGIL is intended for legitimate system monitoring, security observability, administration, and educational purposes.

Only monitor systems and data that you own or have explicit authorization to monitor.

Because system and security monitoring capabilities vary across operating systems, some monitoring features may behave differently depending on platform permissions and available system APIs.

📜 License

This project is licensed under the MIT License.

See the LICENSE file for details.

👨‍💻 Author

Muhammad Abdullah

Computer Science Student & Full-Stack AI Developer

Interested in:

Artificial Intelligence
Cybersecurity
Systems Programming
Full-Stack Development
Software Engineering
Intelligent Monitoring Systems

Observe. Detect. Correlate. Protect.

⭐ If you find this project useful, consider giving the repository a star.

Name		Name	Last commit message	Last commit date
scripts		scripts
src		src
tests		tests
.gitignore		.gitignore
README.md		README.md
config.yaml		config.yaml
main.py		main.py
requirements.txt		requirements.txt
test_core.py		test_core.py
test_vigil_fixes.py		test_vigil_fixes.py

Latest commit

History

Folders and files

Repository files navigation

🛡️ VIGIL — Cloud-Connected System Monitoring & Security Dashboard
